Product Description

New for 2004, Crate introduces an entirely new range of acoustic amplifiers. The technology in the new Crate acoustic series is unique, with preamp circuits you can tailor for piezo or active systems. Their new feedback elimination circuits are efficient and simple to use. They even include the ability to automatically eliminate feedback at two different frequencies. Crate uses special studio monitor-style speakers with polypropylene cones and rubber surrounds in ported cabinets for tight, even bass response. Every CA amp has a high frequency component for crisp, clear highs. The CA6110DG model includes special features for live performance like XLR & 1/4 in. balanced line out with level control which does not affect your stage volume. It also has ground lift on the line out, tweeter level control, effects loop and a two button footswitch for internal reverb/effects and chorus switching. Also included is a wide array of reverbs, delays, chorus and multiple effects settings.

Technical Description

Output power rating: 60 watts @ <1% THD

Channels 1 & 2 low: +/-15dB @ 80Hz

Channels 1 & 2 mid: +15, -30dBdB from 450Hz -- 1.2kHz (Contour)

Channels 1 & 2 high: +/-15dB @ 10kHz

Input impedance: 3.3M ohm High-Z, 3k ohm Low-Z

Input sensitivity: 5mV High-Z, 2mV Low-Z

Sensitivity to effects send/line out: 6mV High-Z, 3mV Low-Z

Max input signal: 6V RMS (17V peak to peak)

CD input impedance: 22k ohm

CD input sensitivity: 150mV

CD input max input signal: 6V RMS (17V peak to peak)

Aux effects return input impedance: 11k ohm

Aux effects return input sensitivity: 60mV RMS

Aux effects return max input signal: 6V RMS (17V peak to peak)

Effects send output impedance: 2.2k ohm

Line out output impedance: 220 ohm Low-Z, 2.2k ohm High-Z

Feedback filters: 10Hz to 4.8kHz range, -15dB cut per filter

Internal woofer: 10 in. w/polypropylene cone, rubber surround, 30.5oz magnet, 1.5 in. voice coil, 8 ohms, 75w RMS, 95dB 1w 1m

Internal tweeter: high efficiency piezo, 110dB 1w 1m

Internal crossover: passive type

Power requirements: 120VAC, 60Hz, 70VA 100/115VAC, 50/60Hz, 70VA 230VAC, 50/60Hz, 70VA

Size and weight: 17 in. H x 16 in. W x 14 in. D, 37 lbs.
