    Eminence ASD-1001 High Frequency Speaker Driver (50 Watts, 1") Product Description

    The Eminence ASD1001 high-frequency driver is a very accurate and extremely clear sounding compression driver designed as a high-quality driver replacement for 1" screw-on type horns. With 50-watts of power rating, diamond titanium diaphragm, and an operating frequency range of 2.5kHz to 20kHz, the ASD1001 is a great choice for a wide range of front of house mains and monitor speaker cabinets, hi packs, both active and passive.

    Same Day Music is an authorized dealer of Eminence products.

    Eminence ASD-1001 High Frequency Speaker Driver (50 Watts, 1") Technical Description

    - Throat Size: 1", 25.4 mm
    - Nominal Impedance*: 8 ohms
    - Power Rating**: 50W @ 2.5kHz
    - Free Air Resonace: 1.23kHz
    - Usable Frequency Range: 2.5Hz-20kHz
    - Sensitivity: 104.3dB (1W/1m across 2.5kHz-20kHz)
    - Magnet Weight: 12oz, 0.34kg
    - Voice Coil Diameter: 1.3" / 33 mm
    - DC Resistance (Re): 6.7
    - Coil Inductance (Le): 1.1mH
    - Overall Diameter: 3.5", 88.9 mm
    - Mounting Holes Diameter: ~
    - Mounting Holes B.C.D.: ~
    - Mounting Thread: 1 3/8" 18 NEF ext.
    - Depth: 2.45", 62mm
    - Weight: 2 lbs, 0.9 kg
    - Diaphragm Material: Diamond Titanium
    - Magnet Composition: Ferrite

    Same Day Music is an authorized dealer of Eminence products.
    Shipping Weights and Dimensions
    8 Ohms
    Shipping Weight: 3 lbs
    Shipping Dimensions: 4 x 4 x 3 in
