Product Description

Top recording studios worldwide use Eventide effects on hit after hit. PitchFactor includes Eventide's best pitch-changing effects from the past 36 years without compromising quality OR flexibility.

Flexibility Built-In
Plug-and-play expression pedal control of wet/dry mix or any combination of parameters. Control program changes and vary parameters continuously via MIDI. Supports instrument or line level inputs and outputs. Plays well with others; adapts seamlessly with a wide variety of amps and other foot pedals.

Obsolescence is so 20th Century
Easy to upgrade; download new software from the Internet and install via USB.

Features
10 of Eventide's signature stereo or mono pitch+delay effects:
- Diatonic
- PitchFlex(TM)
- Quadravox(TM)
- Octaver(TM)
- HarModulator(TM)
- Crystals(TM)
- MicroPitch
- HarPeggiator(TM)
- H910 / H949
- Synthonizer(TM)

Up to 4 voices of diatonic pitch shifting and up to 1.5 seconds of stereo delay

Studio quality sound

Guitar or bass compatible

Built-in Tuner

Software upgradeable via USB 2.0

MIDI control via USB or MIDI in, out/thru

Instant program change

Real-time control with 10 knobs, MIDI, or expression pedal

Tap tempo and MIDI clock sync

100 factory presets, unlimited through MIDI

True analog bypass

Rugged cast metal construction

Reliable metal footswitches for instant preset access

Mono or stereo operation

Guitar or line level inputs and outputs

Technical Description

Analog Input/Output
Input impedance: 500K ohms

Output Impedance: 470 ohms

Recommended Load Impedance: 10K ohms or greater

Connectors
Input 1 (mono): 1/4 inch mono phone jack

Input 2: 1/4 inch mono phone jack

Output 1 (mono): 1/4 inch mono phone jack

Output 2: 1/4 inch mono phone jack

Expression Pedal: 1/4 inch mono phone jack

Aux Switch: 1/4 inch stereo phone jack

USB: Type B Socket. Use 2.0 cables only.

MIDI In: Five pin DIN (Female)

MIDI Out/Thru: Five pin DIN (Female)

AC Adapter Jack: Power Supply included

Physical
Power: 9 VDC, 1200 mA, Tip hot (+)

Dimensions (HxWxD): English: 4.8 x 7.5 x 2.12 in.

Metric: 122 (H) x 190 (W) x 54 (D) mm

Weight 2.15 lbs, 1 kg
