Product Description

The PEM500 Personal Ear Monitor System, offers all of the advantages of wireless in-ear monitoring such as mobility and freedom from feedback. For the first time, a wireless in-ear monitor system combines state-of-the-art advanced frequency-agile synthesized UHF technology, high-end performance, and unprecedented affordability.

Features
16 selectable channels

Lightweight miniature in-ear speakers are supplied

3 different sized of soft rubber mounts for the ideal fit for every user

Body pack features a switchable built-in volume limiter and low battery indicator

Transmitter features a rear-mounted detachable antenna

Front-panel controls for channel selection and input level

Battery life up to 6 hours

Technical Description

Operating Frequency Range: 696-865 MHz, country dependent

Modulation: Mono or stereo (MPX with pilot tone), FM: F3E +/- 60 KHz, nominal

Audio Frequency Response: 50 ~ 12,000 Hz

T. H. D.: 1%

Signal-to-Noise Ratio: > 80 dB, with proprietary companding noise reduction

Operating Range: Up to 300 feet typical (depending on site conditions)

PEM-500T Transmitter
RF Output Power: Max. 50 mW (country dependent)

L/R Audio Line Inputs
Input Impedance: 600 ohms
Nominal Input Level: 0 dBm
Max. Input Level: +6 dBm

Headphones Out Power: 100 mW max. @ 32
