Product Description

The KC-60 3-Channel Mixing Keyboard Amplifier brings renowned KC-Series sound quality to an even lower price. This affordable 40-watt amp is also the first to feature a subwoofer output for enhanced low end. And with 3 separate channels - including an XLR Microphone input and stereo Auxiliary input - the KC-60 is one of the most flexible amps around.

Features:

Compact, affordable keyboard amplifier with legendary KC sound

40-watt output power with 10 in. speaker and independent tweeter

Subwoofer output for low-end boost (compatible with most subwoofers)

3-channel design includes 1/4 in. Line input and XLR Microphone input

Stereo auxiliary input (RCA type) for connecting CD or MD players

Rotary controls for adjusting channel and headphone levels, plus Low and High EQ

Big Sound That's Easy on Your Wallet
Roland's KC-Series Keyboard Amplifiers are known for their exceptional sound quality. That's because they're built to handle the wide range of sounds created by today's synthesizers, samplers and electronic musical instruments. The new KC-60 takes these principles and puts them in a more affordable design, powered by a 40-watt amplifier with a 10 in. speaker and separate tweeter. Now anyone can step up to a KC amp. And once you do, you'll never look back.

Flexible 3-Channel Design with Subwoofer Output
While the KC-60 is built primarily for keyboards, it's also at home with a microphone and CD player. Specifically, there are 3 input channels including an XLR Mic input and Auxiliary input - each with its own adjustable volume. And while 40 watts of power sounds good, you can also add an optional subwoofer from any manufacturer via the KC-60's Subwoofer outputÖa first of its kind on a keyboard amp!

Technical Description

Rated Power Output: 40 W

Nominal Input Level (1 kHz)
Channel 1 (MIC/LINE): -50 to -20 dBu
Channel 2, 3 (LINE): -20 dBu
Aux In: -10 dBu

Nominal Output Level
Line Out: +4 dBu,
Sub Woofer Out: +4 dBu Speakers 25 cm (10 inches) x 1, Tweeter x 1

Connectors
Channel 1 Input Jacks: XLR Type, 1/4 in. Phone Type
Channel 2 Input Jack: 1/4 in. Phone Type
Channel 3 Input Jack: 1/4 in. Phone Type
Aux In Jacks: RCA Phono Type
Line Out Jack: 1/4 in. Phone Type
Sub Woofer Out Jack: 1/4 in. Phone Type
Phones Jack: 1/4 in. TRS Phone Type, Mono signal output

Power Supply AC 117 V, AC 230 V, AC 240 V

Power Consumption: 45 W

Dimensions: 420 (W) x 300 (D) x 410 (H) mm, 16-9/16 x 11-13/16 x 16-3/16 in.

Weight: 12.5kg, 27 lbs 9 oz

* 0 dBu = 0.775 Vrms.

Catalog Description

Compact 40-watt amp@3 channels@RCA aux and XLR mic inputs@10" speaker, piezo tweeter
