Yamaha PLG150AN Analog Synth Plug-In Expansion Board

Email This Page

Voice Memory: 256 Preset, 128 User. Tone Generator AN (Analog Physical Modeling). 3-band equalizer.

This product has been discontinued or is no longer sold by SameDayMusic.

Shop our website for related products:

(In most cases, a product is unavailable because it has been discontinued by its manufacturer.)

Product Rated 9.7 Out of 10 (4 ratings)

FIND SIMILAR PRODUCTS

Yamaha PLG150AN Analog Synth Plug-In Expansion Board Product Description

Same Day Music is an
authorized Yamaha dealer

Reproduce the fat and funky sounds of vintage analog synthesizers. This board gives you a synth engine similar to the one featured in Yamaha's amazing AN1x Analog Physical Modeling Synthesizer. On top of its full array of wave algorithms, resonant filters, LFOs, and envelope generators, it also has distortion and a 3-band equalizer.

Features
Adds physically modeled analog synthesis to the Modular Synthesis Plug-in Systems.

Offers 256 voices: from vintage sounds to the newest dance sounds.

Compatible with the XG Plug-in System.

Works in both the Yamaha S80 and S90ES.

Increases the polyphony of the synthesizer it is installed on, extending the capability of the entire system.

Comes with editors for creating your own sounds, including an "AN Expert Editor" and an "AN Easy Editor" plug-ins for XGworks, a "Free EG" feature for tempo synchronized filter sweeps, and the "Step SEQ" loop sequencer.

Note: Stand alone versions of PLG150-AN Editors are available for download from Yamaha.

Same Day Music is an authorized dealer of Yamaha products.

Yamaha PLG150AN Analog Synth Expansion Board Technical Description

Tone Generator: AN (Analog Physical Modeling)

Maximum Polyphony: 5 notes

Voice Memory: 256 Preset, 128 User

Effects: Guitar Amp. Simulator (Distortion), 3-Band EQ, XG Part EQ

Connector: Plug-in Connector (15 pin Digital I/F connector)

Dimensions: 138.5 W x 8.5 H x 89 D mm

Weight: 65 g

Same Day Music is an authorized dealer of Yamaha products.

User Reviews for Yamaha PLG150AN Analog Synth Plug-In Expansion Board

Product Rated 9.7 Out of 10 (4 ratings)

4 users have rated this product, but no one has reviewed it yet. To rate this item and/or write a review, click the "Rate It" button.
