Yamaha STAGEPAS 500 Compact Portable PA System, 500 Watts

The Yamaha STAGEPAS 500 Portable PA System: Plenty of Power and Inputs for Live Sound On-The-Go.

The STAGEPAS 500 is available for situations in which a little extra power and channel capacity is needed. The basics remain the same: an incredibly lightweight, portable, easy-to-use PA system consisting of a pair of high-performance speakers with a built-in powered mixer. You can be set up and playing in a matter of minutes, and then packed away and on the road again with the same ease and speed when you're done. And all of this is provided with no compromise in sound quality or versatility, plus some advanced features you normally wouldn't expect to find in a system in this class.

Features of the Yamaha STAGEPAS 500 Portable PA System:

Power to Go!

Getting great sound for live performance used to be a big deal. Now all you need is a STAGEPAS 500! It's a high-performance live-sound system that will deliver your music or message wherever you go, indoors or out.

Complete with Speakers, Powered Mixer, and Cables

All-in-one STAGEPAS systems come with a pair of top-quality passive 2-way speakers, a versatile powered mixer, and even a pair of speaker cables!

High-performance 2-way Passive Speakers

STAGEPAS 500 speakers have 10" woofers and 1" high-frequency units, delivering clean, high-quality sound.

Detachable 10-channel Powered Mixer

The 10-channel 250W + 250W STAGEPAS 500 mixer can be used either while installed in the speaker compartment or detached for easy positioning and access.

Convenient Accessory Compartment

Conveniently store cables, microphones, and other small necessities in the speaker accessory compartment for a truly streamlined traveling system.

Optional Microphone Stand Adaptor

The STAGEPAS mixer can be mounted on a microphone stand using the optional BMS-10A adaptor for convenient positioning at any height.

10 Channels and 250W + 250W Power for More Sources and Larger Venues

Dual 250-Watt amplifiers

Two 250-watt power amplifiers can fill surprisingly large clubs or rooms, or project your sound over a considerable distance outdoors. The class-D power amplifier has been painstakingly designed to deliver superior sound quality as well as reliability in a remarkably compact unit.

Versatile 10-channel Mixer with Monitor and Record Outputs

If you have a bunch of band members, or a lot of sources to mix, the STAGEPAS 500 gives you 10 input channels in all: four mono microphone/line inputs and three stereo line inputs. The additional stereo channel can used for either a stereo or mono source. In addition to the main speaker outputs the mixer has line outputs that can be used to connect additional powered speakers for monitoring, and to send the mixer's output to a recording device.

Phantom Power for High-performance Condenser Microphones

The STAGEPAS 500 mixer features switchable phantom power for the four microphone/line inputs. This lets you use high-performance phantom-powered condenser microphones in situations where you want the extended, natural response they provide.

Built-in Channel Compression/Limiting

Channels 1 and 2 feature LIMIT/COMP switches that let you apply either limiting or compression to those channels. Limiting can be useful to prevent input overload and distortion with sources that have a wide dynamic range, while compression can add punch to vocals, bass, guitar, and other sources while smoothing out the sound and helping it to "ride" better in the mix.

2-band Channel EQ and Reverb

The STAGEPAS 500 mixer has 2-band EQ controls on each channel, as well as REVERB switches on channels 1 through 4. A separate REVERB level control adjusts the reverb mix.

Other Features

• XLR and phone-jack inputs on mono channels, and phone-jack and RCA pin- jack inputs on stereo channels allow connection to a wide range of sources.


• MIC/LINE switches select microphone or line level input matching for channels 1 through 4.


• Auto Limiter prevents overload damage to power amplifier and speakers.


• LED output level meter.


• Speaker cables supplied.


• Optional BMS-10A Mic Stand Adaptor for the mixer unit.


• The STAGEPAS 500 speakers can be stand mounted without standard speaker stand adapters.

For Singers

The built-in high-quality reverb is indispensable for great vocal sound, and on the STAGEPAS 500 system the LIMIT/COMP switch can help to deliver smooth, punchy vocal sound.

For Instrumentalists

The STAGEPAS mixer has more than enough input capability to directly handle a range of instruments from electric-acoustic guitars to electronic keyboards.

For Speech

The "SPEECH" mode optimizes the system settings for maximum clarity with speech. Of course, background music from a CD player or other source can be mixed in with the spoken performance.

For Bands

Multiple microphone inputs make the STAGEPAS systems a good choice for band rehearsals or performances. MSR100 powered monitors (sold separately) can be added for monitoring.

The Yamaha Story

Yamaha has been serving the needs of the music community since they manufactured their first reed organs in the late 1800's. Since then, they have expanded their vision to encompass every facet of the music industry. Their holistic approach includes musical instruments, live sound and recording equipment, and music instructional materials.

As one of the few companies to produce both instruments and recording/sound reinforcement products, Yamaha Corporation is in a unique position to improve the overall quality of their line. Their technological advancements in engineering and design can be incorporated into their musical instruments for improved functionality. Similarly, they can ensure their live sound and recording gear is designed to take advantage of the enhanced functionality of their instruments.

High quality standards are apparent in every product Yamaha manufactures. Guitars, basses, drums, keyboards, effects, cables, monitors, digital workstations, mixers, control surfaces, PA speakers, headphones, and more all receive the same attention to detail, for years of trouble-free use.

Same Day Music is an authorized dealer of Yamaha products.

Output Power (Maximum): 250 W + 250 W (10 %)/4ohms at 10 % THD at 1 kHz (Speakers L/R)

Output Power (RMS): 200 W + 200 W/4ohms at 1 % THD at 1 kHz (Speakers L/R)

Maximum Output Level: 116 dB (1 m)

Frequency Response (Nomimal output level at 1 kHz):
-3 dB, 0 dB, +1 dB @ 20 Hz-20 kHz (Music/Speech=Music) (Monitor Out)
-3 dB, 0 dB, +1 dB @ 80 Hz-20 kHz (Music/Speech = Speech) (Rec Out)
-3dB, 0dB, +1 dB @ 20 Hz-20 kHz, 1 W Output (Music/Speech=Music, without Speaker EQ) (Speakers L/R)

Total Harmonic Distortion: 0.5 % at 20 Hz, 1 kHz, 20 kHz +14 dBu Gain - nominal (Monitor Out, Rec Out)

Hum & Noise (Equivalent Input Noise, Rs = 150ohms, Mic/Line = Mic):
-106 dBu (CH1/2)
-112 dBu (CH3/4)
-65 dBu Residual output noise (SPEAKERS L/R)

Crosstalk (1 kHz): -70 dB between input channels

Power Consumption: 65 W

Phantom power Switch: On / Off (CH1-4)

Limit/Comp Switch: On = Comp, Off = Limit (CH1/2)

Input Channel Equalization:
+ 15 dB
High: 10 kHz shelving
Low: 100 Hz shelving

Enclosure: 2 way bass-reflex type, Polypropylene, Black

Crossover Frequency: 4.0 kHz (LF: 12 dB/oct, HF: 12 dB/oct)

Frequency Range: 55 Hz-20 kHz (-10 dB)

Speaker Unit:
LF: 10 in. (25 cm) Cone
HF: 1 in. (2.54cm) Compression Driver

Weight: 52.9 lb. (Speaker x 2 + Powered Mixer)

Dimensions (W x H x D):
13.5 x 21.5 x 11.7 in. (Speaker x 1)
330 x 12 x 175 in. (Mixer)

Same Day Music is an authorized dealer of Yamaha products.

Shipping Weights and Dimensions

Shipping Weight: 64 lbs

Shipping Dimensions: 32 x 25 x 16 in

500-watt portable PA@10-channel powered mixer@Two 10" 2-way speakers@Includes speaker cables
