Product Description

A "Talking" Pedal
The AW-3 Dynamic Wah is the first compact wah pedal to incorporate human voice-type sounds through a new "Humanizer" Mode. Of course, you can also choose from standard up-and-down wah effects, plus a Tempo Mode and resonant synth-like Sharp Mode.

Endless Possibilities
Choose from both fixed and auto wah settings using the Manual control or pedal for tempo input. By connecting an optional expression pedal, the AW-3 can also be used for Pedal Wah effects. A dedicated Bass input permits direct processing of bass guitars.

Features:
Compact pedal creates a variety of classic "wah" effects

Dynamic wah sounds provide variable effect based on picking strength

"Humanizer" effect creates human voice-type vowel sounds

Dedicated Bass input for processing bass guitar

EXP Pedal mode allows wah control via optional expression pedal

Tempo can be set for pedal control or at fixed rate via Manual mode

Boss limited 5-year warranty

Technical Description

Nominal Input Level -20 dBm

Input Impedance 1 M

Nominal Output Level -20 dBm

Output Impedance 1 k

Recommended Load Impedance 10 kor greater

Residual Noise level -95 dBm (IHF-A Weighted, Typ.)

Controls Pedal switch, DECAY knob, MANUAL (VOWEL 2), knob, SENS (VOWEL 1) knob, MODE switch (UP, DOWN, SHARP, HUMANIZER, TEMPO)

Indicators CHECK/TEMPO indicator (Serves also as battery check indicator)

Connectors GUITAR Input jack, BASS Input jack, OUTPUT jack, EXP/TEMPO jack

Power Supply DC 9 V: Dry Battery 9 V type (6AM6/9V), AC Adapter (PSA-series: optional)

Current Draw 45 mA (max)

Dimensions 70 (W) x 125 (D) x 55 (H) mm/2-3/4 (W) x 4-15/16 (D) x 2-3/16 (H) inches

Weight (including Battery): 410 g / 15 oz

Accessories Owner's Manual, Dry Battery (6AM6/9 V)

Ý Options AC Adapter (PSA Series), Expression pedal (Roland EV-5), Foot SW (FS-5U), Dry Battery (6AM6/9 V).
