Product Description

Very loud, touch sensitive and responsive with nice bell sounding top end and a little bite.

Eminence is proud to present the Patriot and Redcoat series of guitar speakers. Incorporating both British and American cone technology into speakers that we manufacture in the USA gives us the ability to provide you with virtually any tone you desire. Be it British or American, clean or dirty, big bass or screaming highs, we have a speaker that will allow you to 'Pick Your Sound'.

Technical Description

Specifications

Power Rating**: 75Wrms/150W peak

Voice Coil Diameter: 1.5 in. (38.1 mm)

Coil Material: Copper

Flat/Round Coil Wire: Round

Coil Former Material: Kapton

Basket Type: Stamped

Cone Surround Material: Paper

Dust Cap Material: Zurette

Magnet Weight: 30oz.

Usable Bandwidth (Fs to -3dB): 70Hz - 5kHz

SPL*: 100dB

* = Published sensitivity is an average of multiple points representing the measured output of the device (1W-1m) across the usable frequency range from 200Hz-5kHz.

** = EIA 426A noise source and test standard. Eminence voice coil technology often results in guitar speakers that dramatically exceed the power rating of other manufacturer's products. Such ratings are not meant to imply the Eminence woofers are not equally suitable for lower-power "Class A" valve amplifiers as they are for high gain valve and transistor amplification.

Mounting Information

Nominal Basket Diameter: 10.11 in. (256.8 mm)

Baffle Hole Diameter: 9.125 in. (231.8 mm)

Mounting Holes Diameter: 0.225 in. (5.7 mm)

Mounting Holes B.C.D.: 9.6 in. (243.8 mm)

Depth: 4.3 in. (109.2 mm)

Shipping Weight: 9 lbs., 4.1 kg.

Product Rated 9.6 Out of 10 (8 ratings)

Read 1 Full Eminence Ragin' Cajun Patriot Guitar Speaker (75 Watts, 10 in.) Review >>

• "All American 10" 75+ watt speaker, nothing better." - Read More
